Wafer Check Valve PN 16 LIV-NRV-CI-NI-002
Lehry Cast Iron Wafer Type Check Valve PN 16
Body: IS 210 GR. Fg 200
Disc : SS 304
Hinge Pin: AISI 316
Stop Pin: AISI 304
Spring: Stainless Steel.
Seat: Nitrile
Mfg STD: API 594
Insp & Test STD: API 594
Ends: Wafer Type to Suite Ansi B 16.1 ( 150#) / PN 16
Hyd -Test Press: Body: 24 kg/cm Sq, Seat: 16kg/cmsq
Additional information
| Pressure | |
|---|---|
| Temperature | |
| Media | |
| Type | |
| Size | |
| End Connection | Wafer Type to suit ANSI B 16.5 ANSI 150#/ PN 16 to EN 1092-2 |
| Seat |
